Universal
Wire Weaving Loom
Features:
-
Machine can produce plain fine-mesh wire netting fabric
-
Available in various types depending on the size of the mesh and the wire gauge
-
The wire material can be Galvanized Iron, Black Iron, Brass, Copper, Stainless Steel, Silver, Platinum, etc.
|
Model:
|
WWL - L
|
WWL - M
|
WWL - H
|
|
Weaving Width (mm):
|
1250
|
1250
|
1250
|
|
Mesh:
|
10 - 100
|
4 - 30
|
2 - 20
|
|
Wire Thickness (mm):
|
0.18 - 0.50
|
0.30 - 1.00
|
0.60 - 1.60
|
|
Speed (Stroke per Minute):
|
60
|
50
|
50
|
|
Motor (HP):
|
5
|
5
|
10
|
|
Net / Gross Weight (Kg.):
|
1300 / 1800
|
2000 / 2500
|
4000 / 4800
|
|
Overall Dimensions (m):
|
2.6 x 2.6 x 1.8
|
2.6 x 2.9 x 1.8
|
2.6 x 3.5 x 1.8
|
|
Shipping Volume (m3
):
|
12.20
|
13.60
|
16.40
|
Bobbin Winding
Machine Model: BWM-5
Standard Accessories:
-
Suitable Electric Motor
-
Starter
-
‘V’ Belts
Auxiliary Equipment:
-
Bobbin Winding Machine
-
Bobbin Stand
-
Finished Wire Cloth Roller
