Coining Press, Hand Press, Flattening
Press, Stamping Press
-
Cylinder Honed and Ram hard chrome plated
-
Double acting cylinder having pressure from both directions
-
Operation with three way directional control valve - Forward, Reverse
& Neutral
-
System equipped with pressure setting valve which helps in setting the
required pressure
Specifications:
|
Model:
|
HCP-100
|
HCP-150
|
HCP-200
|
HCP-300
|
HCP-400
|
|
Capacity (Tons):
|
100
|
150
|
200
|
300
|
400
|
|
Coining Diameter (mm):
|
40
|
50
|
60
|
75
|
100
|
|
Cylinder Bore (mm):
|
200
|
250
|
300
|
350
|
375
|
|
Ram diameter (mm):
|
150
|
175
|
200
|
250
|
300
|
|
Daylight (mm):
|
300
|
300
|
300
|
300
|
300
|
|
Table Size (mm):
|
400 x 400 x 75
|
500 x 500 x 100
|
550 x 550 x 100
|
600 x 600 x 100
|
600 x 600 x 100
|
|
Motor (HP):
|
5.0
|
7.5
|
10
|
15
|
20
|
|
Oil Tank Capacity (Litres):
|
100
|
125
|
150
|
150
|
150
|
|
Approximate Weight (kilos):
|
1000
|
1500
|
2500
|
4000
|
5000
|
|
Dimensions (m):
|
1.50 x 0.80 x
1.90
|
1.70 x 1.00 x
2.00
|
1.85 x 1.10 x
2.15
|
--
|
--
|
|
Shipping Volume (m3
)
|
2.50
|
3.50
|
4.50
|
--
|
--
|
Standard Accessories:
-
Electric Motor
-
Hydraulic Power Pack
-
Starter
VIDEO OF HYDRAULIC COINING PRESS
MODEL: HCP-200
