Fly Ash Brick Making Machines
|
|
| Brick Making Press: Automatic | Brick Making Press: Semi-Automatic |
|---|
- Available in capacity 1000 to 1200 bricks per hour: Automatic
- Also available in capacity 300 to 500 bricks per hour: Semi-Automatic
- Suitable for making quality bricks from industrial wastes like: Flyash, Iron Oxide, Lime Sludge, Quarry Waste, etc.
Brick Making Presses
| Model: | BMP-300/SA | BMP-1000/A |
|---|---|---|
| Type: | Semi-Automatic | Automatic |
| Capacity: | 300 to 500 bricks per hour | 1000 to 1200 bricks per hour |
| Motor: | 7.5 HP | 15 HP |
| Load: | 30 Tons | 30 Tons |
| Brick Size: | 230 x 110 x 75 mm | 230 x 110 x 75 mm |
| Max. size: | 230 x 200 x 100 mm | 230 x 200 x 100 mm |
| System: | Hydraulic, Semi-Automatic, 3 stationed electrical controls | Hydraulic, Automatic, 3 Stationed PLC controlled |
| Table Rotation: | Manual (by pinion and gear) | Hydraulic Motor (Automatic) |
| Mix Feed: | Manual | Conveyor or Manual |
| Brick Removal: | Manual | Manual |
| Approx. Weight: | 2000 kg. | 2500 kg. |
| Approx. Dimensions: | 2.4 x 1.8 x 1.8 m | 2.4 x 1.8 x 1.8 m |
VIDEO OF SEMI-AUTOMATIC MACHINERY FOR MAKING FLY ASH BRICKS
VIDEO OF AUTOMATIC MACHINERY FOR MAKING FLY ASH BRICKS
Pallet Trucks
|
|
|---|
Conveyor
(To feed the mix from the Pan Mixer to the Automatic Brick Making Press)
| Capacity: | 6000 kg. / hour |
|---|---|
| Motor: | 3 HP |
| Bottom end storage: | Intermittent Bin |
| Flow Regulation: | Bin door opening adjustment and Motor ON-OFF |
